Options :

• Spot
• Projection
• Spot/Projection
• PLC-HMI
• Linear Sensor ( upper )
• Smart Electrode ( lower )
• Stroke Adjustable Cylinder
• Stroke End Adjustable Cylinder
• Double Stroke Cylinder
• Flow&Temperature Sensor
• Proportional Valve
• Pressure Sensor
• Barcode Scanner
• Stepped Transformer
• 2nd Welding Cylinder
• Nut&Bolt Feeder

Timers :

• Safco
• Dengensha
• Bosch Rexroth

Related Power at %50 50-60Hz AC	kVA	120	150	180	210	250	300	350
Secondary Short Circuit Current %50	kA	38	42	46	48	50	52	55

Related Power at %50 1000Hz DC	kVA	100 4 DİYOT	150 4 DİYOT	180 4 DİYOT	180 6 DİYOT	250 4 DİYOT	300 6 DİYOT	300 8 DİYOT
Secondary Short Circuit Current (%20-15ms)	kA	35	35	50	75	50	75	95

Projection Arm Length	mm	300 400	300 400	300 400	300 400	300 400	300 400	300 400
Spot Arm Length	mm	400 500	400 500	400 500	400 500	400 500	400 500	400 500
Distance Between Projection Tables	mm	400-650	400-650	400-650	400-650	400-650	400-650	400-650
Force (6 bar max)	daN	730-1400	730-1400	730-1400	730-1400	1200-2400	1200-2400	1200-2400
Stroke (max) (mm)	mm	100	100	100	100	100	100	100
